5-20um Chemical Vapor Deposition Coating Machine with Coating Temperature 200-1050℃

5-20um Chemical Vapor Deposition Coating Machine with Coating Temperature 200-1050℃

20um CVD Coating Machine

5um CVD Coating Machine

PLC Vapor Deposition Coating Machine

Place of Origin:


Brand Name:


Model Number:


Contact Us
Request A Quote
Product Details
Coating Type:
Coating Thickness:
Loading Weight:
Coating Speed:
Heating System:
Electric Heating
Control System:
Coating Pressure Uniformity:
Coating Pressure:
Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
Special wooden box
Delivery Time
5-8 months
Payment Terms
T/T, L/C
Supply Ability
3 sets / month
Product Description

Product Description:

The CVD Coating Machine is a kind of coating process equipment used for surface coating that employs the chemical vapor deposition (CVD) process. It offers a wide range of coating thickness from 5 to 20um and coating speed from 0.1 to 2.0m/min. This CVD coating apparatus is perfect for controlling the temperature of the coating process from 200 to 1050℃, and its PLC control system makes it reliable and easy to use. The CVD coating machine is a reliable and cost-effective solution for surface coating processes. It is widely used in many industries, such as automotive, electronics, and aerospace, and can be used for a variety of coating applications.




Technical Parameters:

Parameter Value
Coating Material Titanium Carbide (TiC);Titanium Nitride (TiN);Titanium Carbonitride (MT/HT-TiCxNy) ;α-Al2O3
Cooling System 2 Sets Of High-performance Water-cooled Condensate Traps
Coating pressure uniformity ±2mbar
Coating Speed 0.1-2.0m/min
Coating Type CVD
Loading Weight 400kg
Coating Temperature 200-1050℃
Heating System Electric Heating
Coating Thickness 5-20um
Coating Pressure 0.1-1.0MPa
Equipment Type Surface Coating Apparatus, Vacuum Coating System, Coating Process Equipment


Ruideer's RDE530L CVD Coating Machine is a professional vacuum coating technique and surface coating apparatus. It adopts advanced CVD (Chemical Vapor Deposition) process and PECVD (Plasma Enhanced Chemical Vapor Deposition) process for coating process equipment. The cooling system features two sets of high-performance water-cooled condensate traps for efficient cooling. The coating speed is adjustable from 0.1-2.0m/min and the power supply is AC380V/50Hz. Moreover, the electric heating system and coating pressure of 0.1-1.0MPa provide users with reliable and stable operation. It is widely used in the industries of optical lenses, LCDs, mobiles, jewelry, watches, toys, auto parts, etc.



CVD Coating Machine
Customized Services of Ruideer RDE530L

Ruideer RDE530L is a CVD Coating Machine with advanced Vacuum Coating Technique and Vacuum Coating System, specialized for Surface Coating Apparatus.

  • Brand Name: Ruideer
  • Model Number: RDE530L
  • Place of Origin: China
  • Coating Thickness: 5-20um
  • Cooling System: 2 Sets Of High-performance Water-cooled Condensate Traps
  • Coating Temperature: 200-1050℃
  • Loading Weight: 400kg
  • Coating Material: Titanium Carbide (TiC); Titanium Nitride (TiN); Titanium Carbonitride (MT/HT-TiCxNy) ; α-Al2O3

Support and Services:

We provide technical support and services for the CVD Coating Machine. Our services include installation, maintenance, training, troubleshooting, and repair. We also provide technical advice and guidance on how to properly use the machine and optimize its performance. We are available 24/7 to answer any questions or address any issues you may have.


Packing and Shipping:

Packaging and Shipping for CVD Coating Machine:

The CVD Coating Machine is packaged safely with foam and plastic to protect against any damages during transportation. The machine is shipped via air or sea depending on the customer's needs. We also offer door-to-door delivery services to ensure the safe arrival of the machine.
