PLC Chemical Vapor Deposition Coating Machine with 2 Sets Water cooled Condensate Traps

PLC Chemical Vapor Deposition Coating Machine with 2 Sets Water cooled Condensate Traps

PLC Chemical Vapor Deposition Coating Machine

2Sets Condensate Traps CVD Machine

Chemical Vapor Deposition Coating Machine 2.0m/min

Place of Origin:

China

Brand Name:

Ruideer

Model Number:

RDE530L

Contact Us
Request A Quote
Product Details
Cooling System:
2 Sets Of High-performance Water-cooled Condensate Traps
Coating Temperature:
200-1050℃
Coating Thickness:
5-20um
Coating Pressure:
0.1-1.0MPa
Power Supply:
AC380V/50Hz
Loading Weight:
400kg
Control System:
PLC
Coating Pressure Uniformity:
±2mbar
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD1200000.00-20000000.00
Packaging Details
Special wooden box
Delivery Time
5-8 months
Payment Terms
T/T, L/C
Supply Ability
3 sets / month
Product Description

Product Description:

The Chemical Vapor Deposition Coating Machine is a type of coating process equipment that is designed to provide an efficient and reliable CVD coating solution. It is equipped with electric heating system, allowing the coating process to be carried out at high temperature, and it also comes with flexible speed control, allowing the coating speed to be adjusted from 0.1 to 2.0m/min. Besides, the machine is capable of carrying a loading weight of up to 400kg, and the coating pressure can be adjusted from 0.1 to 1.0MPa. With its reliable performance and efficient operation, this Coating Process Equipment is suitable for a wide range of coating applications.



Features:



Technical Parameters:

Parameters Value
Heating System Electric Heating
Loading Weight 400kg
Coating Material Titanium Carbide (TiC); Titanium Nitride (TiN); Titanium Carbonitride (MT/HT-TiCxNy) ; α-Al2O3
Cooling System 2 Sets Of High-performance Water-cooled Condensate Traps
Coating Temperature 200-1050℃
Coating pressure uniformity ±2mbar
Coating Pressure 0.1-1.0MPa
Control System PLC
Coating Thickness 5-20um
Power Supply AC380V/50Hz


Applications:

Ruideer's RDE530L CVD Coating Machine is a state-of-the-art surface coating apparatus with a unique electric heating system. It is designed to apply vacuum coating technique to various substrates, including metal, ceramic, wood, glass, plastic, etc. It is capable of providing accurate coating pressure ranging from 0.1 to 1.0MPa, while its two sets of high-performance water-cooled condensate traps ensure the uniformity of coating pressure at -±2mbar. In addition, the loading weight of the machine is up to 400kg.

This CVD Coating Machine from Ruideer is the perfect choice for industrial production lines, thanks to its precise and economical coating process. It is widely used in industries such as aerospace, automotive, electronic, medical, and construction, where it is able to provide smooth and uniform coating for various surfaces. It is also applicable to the decoration and protection of plastic products, furniture, kitchen ware, and other consumer goods.



Customization:

Ruideer provides custom services for its CVD Coating Machine, Model RDE530L. Customers can choose from titanium carbide (TiC), titanium nitride (TiN), titanium carbonitride (MT/HT-TiCxNy), and alpha-Al2O3 as coating materials. Our CVD Coating Machine features a 400kg loading weight and a coating pressure of 0.1-1.0MPa with -±2mbar coating pressure uniformity. The coating temperature can be adjusted between 200-1050℃.

The CVD Coating Machine is an ideal choice for all kinds of surface coating applications, and its vacuum coating technique is reliable and efficient. It is the perfect choice for any vacuum coating needs.



Support and Services:

Technical Support and Services for CVD Coating Machine

We provide a full range of technical support and services for CVD Coating Machine customers.

  • Onsite installation and commissioning
  • Training courses and manuals
  • 24/7 Technical Support
  • Repair and maintenance services
  • Spare parts supply

We are committed to helping our customers maximize the performance of their CVD Coating Machine with the best engineering support and service.



Packing and Shipping:

The CVD Coating Machine's packaging and shipping includes:

  • Wrapping the machine in foam insulation to protect from shock and vibration
  • Placing the machine in a wooden crate for extra protection
  • Securing the crate with metal banding
  • Checking the crate for any signs of damage
  • Labeling the crate with the customer's name and shipping address
  • Shipping the crate to the customer via a trusted delivery service
