Ruideer Sintering Furnace for Mechanical High Performance Titanium Components

Ruideer Sintering Furnace for Mechanical High Performance Titanium Components

  • High Light

    Mechanical Titanium Components Sinter HIP Furnace


    PEG Sinter HIP Furnace


    3 Zone Temp Vacuum Sintering Furnace

  • Usage
    Sintering Furnace, Heat Treatment Furnace, Vacuum Furnace
  • Warranty
    12 Months
  • Weight
  • Voltage
  • Temperature Uniformity
    ±5 ℃
  • Forming Agent
    PEG, Rubber, Resin
  • Place of Origin
  • Brand Name
  • Certification
    CE certificate, GB150, JB4732
  • Model Number
  • Minimum Order Quantity
    1 set
  • Price
    USD 93,000-77,000,000
  • Packaging Details
    Special wooden box
  • Delivery Time
    5-8 months
  • Payment Terms
    L/C, T/T
  • Supply Ability
    7 sets / month

Ruideer Sintering Furnace for Mechanical High Performance Titanium Components

Cost-Effective High-Performance Titanium Components With Superior Mechanical Behavior With Ruideer Sintering Furnace


Technical parameters


Service life 6000times / 20-years service life


Max. Loading weight


≥300kg(According to products and loading space)


Max. Designed temp.


1600℃(Heating temperature)


Max. Working temp.



Max. working pressure



Ultimate vacuum degree

1pa (After heating, under cold,empty,dry condition)


Pumping speed


The vacuum degree is up to 5 Pa within 30min after starting pump. The vacuum degree can reach 3pa after pumping continually within 30min.

Leakage rate (average 24h)


2Pa/h(After testing ultimate vacuum,u nder empty cold, clean condition, test in average 24h)


Wax-collection rate


≥98% (Ar dewaxing with 10kg wax absolutely, average not more than 3 times )


Max. Ramp up rate


8℃/min(Room temperature ramp up to 1450℃ in vacuum,empty loaded condition,can be soaked in process when 600℃,1000℃ and 1200℃.

≥5℃/min when Fully loaded


Cooling time


≤6~7h(From 1480℃ drop to 100℃ when fully-loaded,water temperature≤28℃ )


UPS time


Supply power to indicator and to control furnace when power-off, Keeping time≥80min


Temperature uniformity


YG8 or YC40 control inserts to test:Magnetic saturation deviation after debinding ≤±0.25%,

Coercivity deviation≤±0.3KA/M


Temperature gradient


≤±7℃ (Vacuum sinter to 1450℃,Put ceramic FERRO of grade 334 on flat graphite boards(ceramic FERRO supplied by buyer) ,empty condition,can be soak in process,this test result only as reference)
Heating power 280KVA,Suggest user’s inlet wire:≥180mm2


Temp.measurement Mode


WRe5-26 double-core single thermocouples,mutually redundant,stable and reliable
Temperature control mode 3-zone temp. Control
