Maximize Density: Why Ruideer 6MPa Sinter-HIP Furnace is the Ultimate Solution for Premium Carbide Inserts & Rods

In the competitive world of cemented carbide manufacturing, density is destiny. Whether you are producing high-precision CNC inserts or long carbide rods, internal porosity can lead to inconsistent tool performance, reduced service life, and potential breakage.

To achieve near-theoretical density and superior transverse rupture strength (TRS), you need a powerful ally: The Ruideer 6MPa (60bar) Dewaxing Pressure Sintering Furnace.

Designed specifically for the mass production of Cemented Carbide, Cermets, and Ceramics, our 6MPa series (RDE-3312-6 / 4412-6 / 5518-6) combines industrial robustness with precision control.

The core advantage of our furnace is its Sinter-HIP (Overpressure Sintering) capability. By introducing high-pressure Argon gas (up to 58 bar / 6 MPa) during the liquid phase of sintering, the furnace applies uniform isostatic pressure to the workload.

• Mechanism: This pressure effectively minimizes internal voids and eliminates residual micropores that vacuum sintering cannot remove.

• Benefit: Your inserts and rods will achieve a virtually pore-free structure, significantly boosting hardness and mechanical reliability compared to standard vacuum sintering.

Consistent quality requires consistent heat. Ruideer furnaces feature a scientifically designed graphite hot zone with Multi-Zone Heating Control (3 Zones or 6 Zones depending on model).

• Uniformity Spec: Magnetic Saturation Deviation ≤ ±0.2%; Coercive Force Deviation ≤ ±0.3KA/M.

• Benefit: This ensures that every insert, from the edge to the center of the load, has identical metallurgical properties.

Cleanliness is key. Our furnace is equipped with a high-efficiency Argon Negative Pressure Dewaxing system.

• Wax Collection Rate: ≥ 98%.

• Versatility: Compatible with various forming agents including Paraffin, PEG, and Rubber. This prevents pump contamination and extends equipment life.

Why pay a premium for European brands when you can get the same performance at a better price? Ruideer is a National Manufacturing Single Champion Enterprise in China. We offer:

• Comparable Specs: Same 60bar pressure class, same 1600°C max temp capability, same top-tier components.

• Lower CAPEX: Save up to 30% on investment costs compared to imported equipment, maximizing your ROI.

• Carbide Inserts (CNMG, WNMG): For heavy-duty turning and milling.

• Carbide Rods: For PCB drills and endmills (especially long rods requiring low distortion).

• Mining Tools: For superior impact resistance.

Don't let porosity hold your products back. Join top-tier manufacturers like ZCC-CT and XTC who trust Ruideer for their critical sintering processes.

Contact us today for a customized proposal and see how our 6MPa Sinter-HIP furnace can transform your production quality.
