Cemented Carbide RDE Industrial Vacuum Furnace Automatic Sintering Ar / H2 Gas

Cemented Carbide RDE Industrial Vacuum Furnace Automatic Sintering Ar / H2 Gas

RDE Industrial Vacuum Furnace

Cemented Carbide Industrial Vacuum Furnace

Automatic Sinter HIP Furnace

Place of Origin:

Zhuzhou, Hunan Province, China

Brand Name:

Ruideer

Certification:

CE certificate, GB150, JB4732

Model Number:

Customizable

Contact Us
Request A Quote
Product Details
Effective Space:
Customizable
Color:
Black, Gray, White, Blue
Power Rating:
120KVA/480KVA
Atmosphere Gas:
Ar, N2, He, H2, CH4, CO2
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 93,000-77,000,000
Packaging Details
Special wooden box
Delivery Time
5-8 months
Payment Terms
L/C, T/T
Supply Ability
7 sets / month
Product Description

RDE Furnaces For Cemented Carbide/Industrial Vacuum Furnace Automatic Sintering/Ar/H2 Gas

With our Sinter Furnaces, you can achieve top cemented carbide quality over and over again. The furnaces combine two technologies in one machine: Vacuum sintering and hot isostatic pressing of sintered parts.

In addition to the standard pressure ratings of 10 bar and 60 bar, Sintering Furnaces with process pressure of 100 bar are available for extremely low-cobalt types of cemented carbide. There is also a special high-temperature version of our Sinter Furnaces available, and it is perfect for manufacturing silicon nitride ceramics.

RDE Furnaces for Cemented Carbide

All furnaces can be supplied with pressure ratings of 10, 60, 100 bar. There is a wide range of options available for customized system equipment.

Type  DYL339 DYL4412 DYL5518
Effective space approximately 300 x 300 x 900 mm  approximately 400 x 400 x 1200 mm  approximately 500 x 500 x 1800 mm
Termperature 1600℃ 1600℃ 1600℃
Vacuum leakage rate 2Pa/h 2Pa/h 3Pa/h
Wax-collection rate 98% 98% 98%
Cooling time (sintering temperature—100℃) 40min-150min 120min-360min 180min-420min
Temperature control mode 2-zone/3-zone 2-zone/3-zone 3-zone/4-zone
