Place of Origin:
China
Brand Name:
Ruideer
Certification:
CE
Model Number:
Customizable
Equipment system
It mainly includes control system, heating system, positive and negative pressure debinding system,vacuum system, pressure sintering system, cooling water system, rapid cooling system, safety system and auxiliary system.
Product features:
1. Uniform heating, stable temperature field, accurate temperature measurement and control
2. Tungsten rhenium thermocouple is used for temperature measurement at low temperature (0-1200 ℃); High temperature (1200-2200 ℃) Fluke dual-color infrared thermometer
3. The heating element is designed for rapid disassembly and assembly of graphite parts.
4.The heating element, fixing parts and insulation layer can be used for more than 200 times.
5. Adopt slide valve pump and roots pump unit, including air filtration system
| Furnace Type | Horizontal type(Max Working pressure:58bar/98bar) |
Vertical type (Max Working pressure:58bar/98bar) |
||||
| RDE-3312-N | RDE-4412-N | RDE-5512-N | RDE-5518-N | RDE-1500-N | RDE-3800-N | |
| Usable Space (W*H*L) | 300*300*1200mm | 400*400*1200mm | 500*500*1200mm | 500*500*1800mm | Φ1000*1500mm | Φ3250*3800mm |
| Max.Charge Load | 300kg | 500kg | 1200kg | 1500kg | 1000kg | 4000kg |
| Power Rating | 320KVA | 320KVA | 430KVA | 600KVA | 500KVA | 720KVA |
| Heating Zone | 2/3 Zones | 3 Zones | 3 Zones | 3 /4 Zones | 4 Zones | 6 Zones |
| Cooling time | ≤5h | ≤6h | ≤7h | ≤8h | ≤10h | ≤12h |
|
Empty furnace, cooling from sintering temperature 2100℃ to 100℃. (water temperature≤26℃, water pressure 2-3bar, 55bar(95bar)≤Ar pressure≤58bar(98bar). |
||||||
| Service Life | 20years/6000furnace cycles | |||||
| Max. Working Temp | 2100℃ | |||||
| Temperature Measurement | Special design High temperature W-Re5/26 Thermocouple | |||||
| Max Vacuum Degree | 1Pa (under cold, empty, dry furnace) | |||||
| Leakage Rate | 3Pa/h (Average value under cold, empty, dry furnace) | |||||
| Wax Collection | ≥98%(Argon gas negative dewaxing, 3-time average value) | |||||
| Forming Agent | Paraffin,PEG,Rubber,(C12H22O5)n etc. | |||||
| Input gas | N2, Ar, H2 | |||||
| Functions | Automatic Positive Pressure, Negative Pressure Leak Detection Ar Negative Pressure Dewaxing/H2 Micro Positive Pressure Dewaxing Vacuum Sintering Partial Pressure Sintering (Static, Dynamic) Pressure Sintering Rapid Cooling Fully-automatic control & Safety interlock& Breakpoint continuing heating & Wireless remote control& Self-diagnosis |
|||||
