High Performance Metal Sintering Furnace With Vacuum Dewaxing / H2 Dewaxing Function

High Performance Metal Sintering Furnace With Vacuum Dewaxing / H2 Dewaxing Function

  • High Light

    hip furnace

    ,

    hot isostatic pressing machine

  • Name
    Metal Sintering Furnace
  • Effective Space
    Customized
  • Usage
    Copper-base Alloy, Aluminum , High Density Alloy, Tungsten-nickel Alloy.ect
  • Functions
    Vacuun Dewaxing, H2 Dewaxing, Vacuum Heating, Heating With Gas Mixture(Co2 /CH4/H2), Heating Flowing Gas, Heating Pressure Gas, Rapid Cooling.
  • Cooling Period
    40min-480min
  • Maximum Load
    50Kg-2000Kg
  • Place of Origin
    Zhuzhou City, Hunan Province,China
  • Brand Name
    Ruideer
  • Certification
    CE;ISO9001;ISO14001;OHSAS 18001;GB/T29490
  • Minimum Order Quantity
    1 set
  • Price
    80000.00—1000000.00(USD)
  • Packaging Details
    Special wooden case packing
  • Delivery Time
    100-120 work days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    8 sets/month

High Performance Metal Sintering Furnace With Vacuum Dewaxing / H2 Dewaxing Function

High Performance Metal Sintering Furnace With Vacuum Dewaxing / H2 Dewaxing Function





Functions:

Vacuun dewaxing, H2 dewaxing, vacuum heating, heating with gas mixture(Co/CH4/H2), heating flowing gas, heating pressure gas, Rapid cooling.





Description:

1. The sintering HIP furnace is single-chamber, horizontal and periodic heating. It adopt low voltage and large current graphite heating element to heating, and it has multiple heating units, each unit controls the temperature separately. The whole process is automatically controlled, monitored, tracked and displayed and recorded by the computer.

2. It including control system, heating system, debinding system(negative pressure debinding system), vacuum system, partial pressure sintering system, pressure sintering system, cooling water system, rapid cooling system, auxiliary system and safety system.

3. It adopt the structure of built-in graphite liner in insulation tube. In the mass, it can meet the strict requirements of furnace temperature uniformity and atmosphere uniformity in the sintering process of high performance cemented carbide.





Applications:

For Cemented Carbide, Precision Ceramic, stainless steel, Iron-bae alloy, Copper-base alloy, Aluminum , high density alloy, tungsten-nickel alloy, tungsten-copper alloy, titanium alloy, carbon-atmosphere-sensitive metal products.



Technical parameters:





Specifications

RDE-DYL-224 RDE-DYL-336/RDE-DYL-339 RDE-DYL-3535120/RDE-DYL-4412 RDE-DYL-5512/RDE-DYL-5518 RDE-DYL-5527

Effective space(w* h * l)mm

200*200*400

300*300*600/

300*300*900

350*350*1200/

400*400*1200

500*500*1200/

500*500*1800

500*500*2700

Max.Temperature

1600℃ 1600℃ 1600℃ 1600℃ 1600℃
Maximum load 50Kg 150Kg/200Kg 300Kg/350Kg 1200Kg/1500Kg 2000Kg

Vacuum leakage rate:(Average in cold,empty,dry chamber in 3 hours)

1Pa/h 2Pa/h 2Pa/h 3Pa/h 3Pa/h
Extreme vacuum 0.8Pa 0.8Pa 0.8Pa 1Pa 1.5Pa
Wax-collection rate(negative pressure dewaxing process.The maximum average value is 3 furnaces) 98% 98% 98% 98% 98%

Working pressure

1MPa/2MPa/

6MPa/10MPa

1MPa/2MPa/

6MPa/10MPa

1MPa/2MPa/

6MPa/10MPa

1MPa/2MPa/

6MPa/10MPa

1MPa/2MPa/

6MPa/10MPa

Cooling period(Sintering temperature—100℃)

40min-120min 40min-150min 120min-360min 180min-420min 180min-480min

Temperature control mode

Single zone/2-zone

2-zone/3-zone

2-zone/3-zone

3-zone/4-zone

4-zone

Atmosphere and temperatureuniformity

Com≤±0.15%

Hc≤±0.25KA/M

Com≤±0.15%

Hc≤±0.25KA/M

Com≤±0.2%

Hc≤±0.3KA/M

Com≤±0.2%

Hc≤±0.3KA/M

Com≤±0.2%

Hc≤±0.3KA/M

Input gas allowed

Ar,N2,He,H2,CH4,Co2

Functions:Vacuun dewaxing,H2 dewaxing,vacuum heating,heating with gas mixture(Co2 /CH4/H2),heating flowing gas,heating pressure gas,Rapid cooling.


Competitive Advantage:



1. Compact structure , small occupation area, low energy consumption, rapid cooling speed, saving energy and protecting environment.

2. Full range of sizes available, canbe usedin experimental research and development, Small and medium-sized enterprises as well as mass prodution. We can design the procucts according to customer’s special requirement

3. Complete after-sales service system: Provides 7 x 24 hour telephone hotline. Propose solutions within 2 hours after receiving the customer's fault notice. With 15 experienced professional after-sales service staff, not only responsible for the company's product installation and debugging, but also for the need of users to complete the domestic and foreign manufacturers of sintering furnace after-sales and maintenance work.

4. Convenient service: If the customer has the demand may carry on the sintering product test in the Ruideer company site, and the company production site has the hot state pressure condition.

5. Quick installation : The installation can be completed and put into production within 15 days when water, electricity and gas are in place.

6. High automation level : one-button start, Double industrial PC operating system, mutually redundant,safe and reliable.

7. The control system is full-automatic with data record &backup function, the operation system is more humanized,more powerful.

8. The Insulation box is of good insulation effect, free of volatilization athigh temperature, with long life.It adopts “sandwich structure”and CFC material inside and outside with high strength, will be no deformation afteer many years use.

9. Program has resume-heat-at-breakpoint function, no need to restart the program in case of short time power failure.

10. Convenient and intelligent: The control interface of sintering furnace can be monitored by mobile phone,control and understand the running state of the equipment anytime and anywhere. Fully automatic one-key operation function, realize the supervision of multiple devices by one person, intelligent production, and docking ERP management system.
